Electrical
|
|
| Non-Volatile Memory |
Programming And Log |
| Output |
To Land line Connection |
| Quiescent Current |
20milli amp Typical With All Led�s. |
| Required |
Active Land line Connection |
| Zone Loop Resistance |
< 5kilo Ohm For Normally Closed |
| Zone Response Time |
< 500 Millisecond |
Power Supply
|
|
| Mains Supply Voltage |
12v+/-24v Dc |
| Total Current Output |
250 Milli Amp (Max) |
| Regulation |
< 9% |
| Ripple |
<200milli Volt RMS |
Environmental
|
|
| Environment |
Residential/ Commercial/ Light Industrial |
| Maximum Humidity |
95% Non-Condensing |
| Operating Temperature |
0�C To 45�C |
| Storage Temperature |
-20�C~+60�C |
Physical
|
|
| Colour |
Grey Coloured Metal Box |
| Control Panel Dimension |
(H X W X L)=150 X 50 X 125mm |
| Weight |
0.600gm |
